Vertex SynTech designs support structures around industrial machines, their loads, the people who access them and the cleaning process. The scope ranges from individual equipment supports to integrated packaging-line structures.
Talk to our engineering team
EXPLORE THE CAPABILITIES
Multihead weigher mezzanines support weighing equipment and provide access around it. Vertex SynTech designs the structure around the specific weigher model, surrounding machines and operating conditions.
Explore capability: Multihead weigher mezzaninesFeeder and conveyor support frames position ancillary equipment beside production, dosing and packaging machines. Their geometry must connect the product flow while preserving access and equipment stability.
Explore capability: Feeder & conveyor support framesMaintenance and operator platforms provide access around industrial equipment for operation, service, cleaning, changeover and inspection. Layout and configuration depend on the process.
Explore capability: Maintenance & operator platformsMultihead weigher wash walls provide a dedicated place to clean, drain and store removable weigh hoppers. The arrangement is configured to the weigher model, hopper geometry and hopper count.
Explore capability: Multihead weigher wash wallsRobot pedestals provide a mounting foundation for robotic handling. Vertex SynTech considers robot payload, reach, acceleration and anchoring requirements together with the installation environment.
Explore capability: Robot pedestalsPick-and-place gantries provide overhead support for robotic product handling. The design relates the robot envelope and tooling to the conveyor height and the required equipment access.
Explore capability: Pick-and-place gantriesMaterial and finish selection follows the hygiene zone, cleaning regime and budget. Vertex SynTech’s support-structure options include painted carbon steel, 304 stainless steel and 316 / 316L stainless steel.
Explore capability: Materials & finishes for support structuresLoad-bearing structures accommodate weighers, feeders, conveyors, elevators, robots and other process or packaging equipment. Stairs, platforms, handrails, kick plates and service clearances provide the access around them.
Custom 3D layouts account for customer equipment and factory constraints. New lines, retrofits and line upgrades can require different arrangements for maintenance, cleaning, changeover and everyday operation.
Machine bases, support frames and special structures are part of the offering. Dimensions, machine interfaces, mounting zones and loads define the starting point for a project-specific stand.
Integrated structures can connect multiple machines and processes within a packaging cell. The design considers the equipment arrangement together with access, clearances, drainage and installation requirements.
Define the machine models, static and dynamic loads, footprint and deck height. Add hygiene zone, drainage, routing and access requirements before fabrication.
